UBA 2202i – Mini Class D Stereo Amplifier
2x 20W Mini Class D stereo amplifier for media applications, museums, hotels, etc. Can also be used in bridge mode. A remote 24 V switching power supply is included.
Automatic on/off, screw terminal inputs, 2 symmetrical inputs for long distance operation, mic/line switchable, built-in limiter, etc.
Technical Data:
| Name: | UBA 2202I |
| Item no.: | 104524 |
| Output power: | STEREO mode: 2 x 4-8 Ohm / 20 W BRIDGE mode: 1 x 8 Ohm / 40 W |
| Input sensitivity: | MIC: 5 mV at 600 Ohm LINE: 775 mV at 10 kOhm |
| Signal-to-noise ratio: | > 85 dB |
| Total Harmonic Distortion (THD): | <1% |
| Operating voltage: | 24V DC / 3 A |
| Dimensions (in mm): | 230 x 115 x 56 |
| Weight: | 1.9 kg |
